Coil lath

Coil lath

Coil lath

Expanded metal lath

Galvanised steel Coil lath

Galvanized wide Coil lath

Description

Coil lath is extensively used as a background to plaster in order to reinforce against cracks and it is especially useful at joints of dissimilar materials. The main width of Coil lath are 100mm, 150mm, 200mm, 300mm. The length can be 50/100m/ coil.
Coil lat have strengthening cornices, low walls and balconies over door and window openings.

Specification

Model
Weight(Kg/m2)
Coil width(mm)
Coil length(m)
Materials
GCL-B 150
0.6
150
50
GI steel
GCL-B 200
0.6
200
GCL-L 150
0.91
150
GCL-L 200
0.91
200
GCL-M 150
1.11
150
GCL-M 200
1.11
200
GCL-H 150
1.61
150
GCL-H 200
1.61
200
GCL-E 150
1.85
150
GCL-E 200
1.85
200
GCL-S 150
2
150
GCL-S 200
2
200
SCL-B 150
0.6
150
SS
SCL-B 200
0.6
200
SCL-L 150
0.91
150
SCL-L 200
0.91
200
SCL-M 150
1.11
150
SCL-M 200
1.11
200
SCL-H 150
1.61
150
SCL-H 200
1.61
200
SCL-E 150
1.85
150
SCL-E 200
1.85
200
SCL-S 150
2
150
SCL-S 200
2
200

Notice: special length and width of Coil lath are available upon request.
