Strip lath

Strip lath

Strip mesh

Strip mesh lath

Strip mesh

Strip mesh lath

Description

The Strip Mesh Lath is produced for use along stress lines where cracking is likely to occur. The strip lath used to provide reinforcement base to plaster between dissimilar building areas and at crack-prone areas adjacent to openings. Galvanized strip mesh is used for internal application and stainless steel strip mesh is used for external application.

Materials standard

All galvanized materials are manufactured from steel to DX51.BSEN 10142 (g 275). Stainless steel materials are manufactured from steel to EN 10088-2 grade 1.4301 (standard supersedes BS1449 Part 2: 1983 grade 304 S15).

Specification

Model
Mesh size(W*L mm)
Weight Kg/m2
Packing
Materials
GSL-1
150*2500
0.91
10pcs/bundle
GI Steel
GSL-2
1.1
GSL-3
1.61
GSL-4
1.85
GSL-5
200*2500
2
GSL-6
0.91
GSL-7
1.1
GSL-8
1.61
GSL-9
1.85
GSL-10
2
SSL-1
150*2500
0.91
SS
SSL-2
1.1
SSL-3
1.61
SSL-4
1.85
SSL-5
200*2500
2
SSL-6
0.91
SSL-7
1.1
SSL-8
1.61
SSL-9
1.85
SSL-10
2

Storage

Avoid bending or other damage and store in a dry place protected from moisture, store away from acids and incompatible materials
