7/8” Hi rib lath
Hi rib lath
Galvanized steel rib lath
Metal rib forming lath
7/8” Hi rib lath
7/8'' High rib lath
Description
7/8” high rib lath, are expanded metal laths stiffed with longitudinal ribs. The furring design of the mesh provides efficient background plaster for construction of partition, suspend ceiling and refurbishment works, when a key for rendering is not certain due to disintegration or softening of wall face.
Features:
More rigid;
Greater stiffness;
Wider spacing;
Easy keying of plaster
Matertal:
0.3-0.7mm Stainless steel or 0.3-0.7mm galv. steel
Specification
Model |
Rib height |
Rib distance (mm) |
Width
(mm) |
Aperture size (mm) |
Remark |
AB-1/8-4-75-450 |
1/8" |
75 |
450 |
9*17 |
9-rib & 4-aperture |
AB-3/8-4-75-450 |
3/8" |
450 |
|||
AB-1/8-4-75-600 |
1/8" |
600 |
|||
AB-3/8-4-75-600 |
3/8" |
600 |
|||
AB-1/8-4-75-750 |
1/8" |
750 |
|||
AB-3/8-4-75-750 |
3/8" |
750 |
|||
AB-1/8-8-100-600 |
1/8" |
100 |
600 |
7*11 |
7-rib & 8-Aperture |
AB-3/8-8-100-600 |
3/8" |
||||
AB-3/4-8-100-600 |
3/4" |
||||
AB-5/8-8-100-600 |
5/8" |
||||
AB-7/8-8-100-600 |
7/8" |
||||
AB-1/8-4-100-600 |
1/8" |
9*20 |
7-rib & 4-aperture |
||
AB-3/8-4-100-600 |
3/8" |
||||
AB-3/4-4-100-600 |
3/4" |
||||
AB-5/8-4-100-600 |
5/8" |
||||
AB-7/8-4-100-600 |
7/8" |
||||
AB-1/8-8-150-600 |
1/8" |
150 |
600 |
11*17 |
5-rib & 8-aperture |
AB-1/4-8-150-600 |
1/4" |
||||
AB-3/4-8-100-700 |
3/4" |
100 |
700 |
7.2*9.5 |
5.66kg |
AB-7/8-8-100-700 |
7/8" |
100 |
700 |
7.2*9.5 |
6kg |
AB-3/8-8-98-686 |
3/8" |
98 |
686 |
7.2*9.5 |
3.34kg |
AB-3/4-8-98-686 |
3/4" |
98 |
686 |
7.2*9.5 |
5.4kg |
AB-3/8-10-98-686 |
3/8” |
98 |
686 |
7.2*8.2 |
3.2kg |
Application
Rib lath is idea for refurbishing damaged or aged masonry walls, when a key for rendering is not certain due to disintegration or softening of the wall face. Lath should be fixed with apexes of ribs against the wall, edge ribs of sheets nesting into each other should be wire-tied every 15cm and ends of sheets should be lapped not less than 2.5cm and nesting ribs securely tied together. Stainless steel fixing should be used at sufficient intervals to hold the lath firmly in position.Competitive advantages
Good and high quality control , prompt delivery , new product , competitive prices , earth-friendly products
